[SBS050] Sungrow Battery modules 5.12 kWh Max 1 Phase

Battery modules 5.12 kWh Max 1 Phase
Battery type LiFePO4 Prismatic Cell
Battery module 5.12kWh
Nominal voltage 102.4V
Operating voltage 86.4 V - 116.8 V
Rated charging/discharging current: continuous  30 A ( charging ) / 50 A ( discharging )
Max. charging/discharging current 50 A ( charging ) / 50 A ( discharging )
Display SOC indicator, Status indicator
Communication interface CAN
Over/under voltage protection Yes
Over current protection Yes
Over/under temperature protection Yes
DC breaker Yes
Dimensions (W*H*D) 515 mm * 780 mm * 182 mm
Weight 58kg
Installation location Indoor / Outdoor
Mounting method Floor stand / Wall-mounted
Operating ambient temperature range Charge：0 ℃ - 55 ℃ Discharge：-20 ℃ - 50 ℃
Degree of protection IP55
Allowable relative humidity range 0 % - 95 % no condensing
Max. operating altitude Max. 2000 m
Cooling method Natural convection
Certificates UN 38.3, IEC 62619
